Electro-Voice EKX-12

Availability:

Out of stock
Brands: Electro-Voice
Brands
  • 1400W peak power
  • 90° x 60° pattern coverage for best coverage on mid-size stages
  • 40° monitor angle with rubber feet
  • Lightweight, compact 15mm wood enclosure with internal bracing and durable EVCoat finish

$1,029.00

Out of stock

Series EKX-12 12″ Two-Way Loudspeaker (Black)

The black EKX Series EKX-12 Two-Way Loudspeaker from Electro-Voice comes housed in a robust and compact wood enclosure with durable EVCoat finish. The Signal Synchronized Transducers (SST) waveguide design provides precise coverage and good sound quality at high SPLs. The 12″ EVS-12M woofer, coupled with a DH-1M 1″ titanium compression driver, allows the EKX-12 2-way loudspeaker to deliver SPL of up to 131 dB. It is suitable for a wide range of sound reinforcement scenarios including musicians/DJs and live/club/installed sound applications.

FEATURES

  • 1400W peak power
  • 90° x 60° pattern coverage for best coverage on mid-size stages
  • 40° monitor angle with rubber feet
  • Lightweight, compact 15mm wood enclosure with internal bracing and durable EVCoat finish
  • Eight M10 threaded mounting points, aluminum pole-mounts, and all-metal handles
  • EKX-12: 1400 W (peak), 131 dB peak SPL utilizing high-sensitivity transducers designed and engineered by EV.
  • EV-patented Signal Synchronized Transducers (SST) waveguide design provides precise and consistent coverage.
Categories: , , Tags: , Brand:
Brands

Electro Voice
Product Type

PA Speakers, Portable PA Systems
Active or Passive Passive
Frequency Response At -3 dB: 82 Hz to 18 kHz

At -10 dB: 55 Hz to 20 kHz

Full space measurement
Frequency Rec. High-Pass: 55 Hz
Power Capacity 350 W continuous, 1400 W peak
Axial Sensitivity 55 Hz to 20 kHz

Full space measurement
Maximum Sound Pressure Level (SPL) 131 dB

Maximum SPL is measured at 3.3′ (1 m) using broadband pink noise at rated peak power rating
Impedance Nominal: 8 Ohms

Minimum Impedance: 7.5 Ohms
Crossover 1.6 kHz
Coverage 90° x 60°
Low Frequency Driver EVS-12M 12″ (30 cm)
High Frequency Driver DH-1M 1″ (2.54 cm) titanium compression driver
Enclosure Material 0.6″ (1.5 cm) plywood with EVCoat finish
Grille 18 AWG steel with powdercoat
Input Connections Dual NL4
Suspension 8 x M10 threaded mounting points
Dimensions 24 x 15 x 14″ (607 x 375 x 356 mm)
Weight 38.3 lb (17.4 kg)

Packaging Info

Package Weight 44.28 lb
Box Dimensions (LxWxH) 26 x 16.2 x 15.75″
