Proel LTX10PWV2

LTX is a complete series of active and passive loudspeakers specifically designed for a wide range of commercial and residential installations. The speaker systems are housed in robust multilayer wooden cabinets available in black or white, offering a refined and discreet aesthetic suitable for any environment.

All cabinets feature multiple suspension points and dedicated accessories for a wide variety of mounting options. The KPTLTP bracket (included with the LTX6 and LTX8) allows wall and ceiling installation with adjustable tilt and orientation for more uniform coverage. The C-brackets (for the LTX10 and LTX12 models) enable discreet installation on walls, ceilings, and stage structures. The LTX8, LTX10, and LTX12 are also equipped with a standard pole mount adapter, allowing use as portable sound systems with standard speaker stands.

For high-frequency reproduction, symmetrical 90° × 90° dispersion horns have been designed to provide consistent coverage for large audiences in both vertical and horizontal installations, delivering detailed sound with low distortion. High-excursion woofers combined with carefully tuned bass reflex cabinets provide extended response with deep and fast bass.

The active versions are powered by amplifiers featuring the latest technologies, including Switch Mode power supplies and CLASS D power stages, delivering high power with reduced size and weight. They include sophisticated preamplifier sections with phase-aligned crossover filters up to 24 dB/oct., active EQ filters for system tuning, and POWERCON connectors. Independent HF and LF limiter circuits ensure distortion-free sound at high levels and complete loudspeaker protection.

The passive versions feature carefully designed linear-phase crossover filters, HF protection circuits, and SPEAKON connectors.

FEATURES

• 1” compression driver
• 10” woofer
• Coverage: 90° H × 90° V
• Peak power handling: 500 W
• Frequency response: 60 Hz – 20 kHz
• Sensitivity: 94 dB SPL (1W/1m)
